liquefied gas CS6CT-P
Camsler Natural Gas Engine: Optimized for Biomass and Landfill Gas EfficiencyOur integrated solution for biomass and landfill gas utilization employs dual technologies—precision combustion optimizatio
Product Details
Product Model
Product Description
Camsler Natural
Gas Engine: Optimized for Biomass and Landfill Gas Efficiency
Our integrated solution for biomass and landfill gas utilization employs dual technologies—precision combustion optimization and waste heat recovery—to achieve a system-wide energy efficiency of 87%. The unique exhaust design maintains NOx emissions below 2 g/kW·h, meeting the strictest standards including China VI and Euro V. An ideal choice for distributed energy power stations, this solution reduces annual carbon emissions equivalent to planting 6,000 trees.
|
型号/Model |
CS6CT-P165 |
CS6CT-P181 |
|
进气方式/Intake Mode |
增压空空中冷/Turbocharged and Air
Cooled |
|
|
额定功率Kw/Rated Power |
150 |
165 |
|
备用功率Kw/Standby
Power |
165 |
181 |
|
气缸数/No.of
Cylinders |
6 |
|
|
缸径mm/Bore |
114 |
|
|
行程mm/Stroke |
145 |
|
|
压缩比/Compression
Ratio |
11.5:1 |
9.5:1 |
|
频率Hz/Frequency |
50HZ |
60HZ |
|
额定转速rpm/Rated Speed |
1500 |
1800 |
|
排量L/Displacement |
8.9 |
|
|
润滑液容量L/Lube
Capacity |
27.6 |
|
|
冷却方式/Cooling System |
强制水冷循环/Forced Water Cooling
Circulation |
|
|
启动系统/Starting
Method |
24V电启动/24V Electric Start |
|
